Nodes Explained

An overview of the node types in the Conversation Flow and the parts every node editor has in common.

Nodes are the building blocks of the Conversation Flow. Each node does one job – says something, waits for the customer, decides, calculates, asks a language model, or hands the conversation over – and points to the node that comes next.

This chapter explains every node at the configuration level. For a hands-on walkthrough, see Creating Your First Project.

A conversation flow on the canvas
A small invoice-support flow that uses every node type

Nodes list


Node types and names

Every node name starts with a fixed prefix that tells you its type. You type only the rest of the name; letters are converted to upper case and spaces to _.

Node
Prefix
Example

Start

–

START (one per flow)

Message

MSG_

MSG_WELCOME

Answer

ANS_

ANS_MAIN_TOPIC

Decision

DEC_

DEC_CUSTOMER_TYPE

Function

FNC_

FNC_LOAD_CUSTOMER

AI

AI_

AI_ASSISTANT

Transfer

TRAN_

TRAN_VIP_SUPPORT

Redirect

RDRCT_

RDRCT_BILLING_TEAM

End

END_

END_DONE

A new node is called NODE_<number> and its editor opens with the name field ready. If you close it without a real name, or with a name another node already uses, a warning reminds you to rename it.

Adding nodes

The Nodes panel
The Nodes panel
  • From the Nodes panel in the top-left corner of the canvas: drag a node onto the canvas, or click it and then click where it should go (press Esc to cancel). Nodes added this way are not connected yet.

  • From another node: hover over a node that has a free output and click the arrow next to it. Pick a node type and the new node is created and connected.

  • From a target field: when a Next field is empty, its list starts with Create a new node: – pick a type to create, connect and open the new node.

Adding a connected node from the hover arrow
Adding a connected node from the hover arrow

The node editor

Double-click a node to open its editor. Alt + double-click opens the editor docked to the left, so the canvas stays visible. There is no Save button – closing the editor saves your changes.

Every editor shares these parts:

  • Header – the node name with a pencil icon to rename it, and arrows to jump to the previous or next node.

  • Tools – smart functions the node runs, for example a date extractor or an API call. Click Add, pick the tool from the catalogue and name the variable that receives its result.

  • Variables – values the node sets, written as Python-style expressions: "text" for text, 32 for a number, True/False, or the name of another variable.

  • Next – the node the conversation continues to. Turn on Dynamic to take the next node's name from a variable instead.

Tick the checkbox of one or more tools or variables to Copy to node (to another node, or the same node to duplicate them) or Delete them. Drag the handle on the right to change their order – they run from top to bottom.

Insert a variable into any text field by typing { or clicking the {x} icon. During the conversation, {customer_name} is replaced by the variable's value.

Working on the canvas

  • Right-click a node to Group nodes or Remove node. Right-click a selection of nodes (Shift + click or Shift + drag) to group, remove or Copy / Paste them.

  • Groups are coloured frames that keep related nodes together. Right-click a group to rename it, change its colour, detach its nodes or remove it.

  • Reference nodes replace a long connection with a shortcut: right-click a connection and choose Reference node. Double-clicking a reference opens the original node.

  • Comments – click the speech-bubble icon in the top bar, then click a node or the canvas to leave a comment for your team.

  • Ctrl/Cmd + C and Ctrl/Cmd + V copy and paste nodes, also between projects. Pasted nodes get the suffix _COPY and appear under the mouse pointer, or in the middle of the view. Ctrl/Cmd + Z and Y undo and redo.

Groups, comments and reference nodes only help you organise the canvas – they don't change how the conversation runs.
